Trade name/synonym name: Coumarone oil; DRO; Distillates(petroleum), steam cracked, C8-C12 fraction; Distilled resin oil; High DCPD Resin oil
Amber to yellow coloured liquid with a strong aromatic or camphor odour. Liquid is flammable and toxic. Vapour pressure @ 20°C < 5 kPa (not suitable for ventilation) and Density 930 - 950 kg/m3 @ 20 deg. C
IBC carriage requirements:
IBC chapter 17
Ship Type 2
Tank Type 2G
Relevant additional IBC req.
15.12 Toxic products. Requirements to exhaust openings of vent systems. Connection for vapour-return line to the shore installation. Not to be stowed adjacent to oil fuel tanks. Separate piping systems. Cargo tank relief-valve setting minimum 0.02 MPa gauge (= 200 mBar)
15.19.6 high-level alarm
“T” an instrument or detector tubes for detection of toxic cargo vapours shall be on board
MARPOL Requirements:
Annex II
Pollution Category Y
Special information to be added to Shipping Document - Standard information
Stowage Heat adjacent 45 deg C
Stow adjacent to fuel oil tanks No
Carriage requirements:
Heating during voyage No
Heating during unloading No
Tanks inerted or padded Not required by IBC
Prewash required? No prewash required by MARPOL Annex II.
Tank cleaning:
Ambient temperature water wash
Hot temperature water wash
If next cargo requires very clean tanks: warm temperature freshwater wash added cleaning additive (hydrocarbon remover)
Ambient temperature freshwater rinse
Emergency Response: Fire: Use foam or water spray - not water jet
Spillage: Eliminate sources of ignition. Collect small spills with absorbent material. Larger spills: Try to collect and transfer to spill tank or wash away with water. When in port, - inform Port Authority
First aid: Remove victim to fresh air. Follow first aid instructions in MSDS. Consider obtaining advice from Radio Medical
Hazards (Occupational safety etc):
This product contains several minor components that have demonstrated toxic effects. Obtain specifications. Wear gas tight chemical protection suit and self-contained breathing apparatus when handling cargo spill and when there is a risk of getting into contact with cargo liquid or vapour
Precautions: Stable flammable product, Possible dangerous reaction with oxidizing material such as for example nitric acid.
Remarks: Strong odor - difficult to remove. Not recommended to be carried prior to sensitive cargoes.
Resin oil is used to produce hydrocarbon resins. Major applications of these resins are in printing inks, hot melt pressure sensitive adhesives, rubbers, paints, varnishes and road marking paints. Furthermore, the resins can be used in concrete curing additives, sealings, floor-tiles, foundry core binding and for paper sizing.
